Load Management / Surge Protection
Residential and commercial self-contained meter sockets configured for underground operation.
Features:
Rating: 60 hertz, 200 amps, 600 volts AC
Type: Ringless meter socket
Jaws: 4, 5, and 7 terminal configurations available
Service Type: Underground
Wire Terminals: 3/8” studs, or single port #350kcmil lugs
Ground: #2-14 screw-type terminal
Provided Neutral: Isolated
Mounting: Six mounting embossments
Construction: 14-gauge galvanized G-90 steel, grey powder coat finish
Knockouts: (5) bottom, (2) back, (1) left side, (1) right side
Industry Standards:
ANSI C12.7
UL 414 Listed
Designed to NEMA Type 3R
Options:
Barrel lock provision
Hubs
Cover plate
Contact Brooks for additional details and model numbers.
