10266 Large Load Series

10266 Series (Large Load)

Brooks Utility Products’ 10266 Series is engineered for high-capacity applications, providing precise, utility-grade primary metering for the largest medium-voltage power loads like data centers and utility-scale renewable energy integration. These heavy-duty 35kV Large Load units are rated for 150kV BIL and available in 200A or 600A configurations, featuring a robust NEMA 3R bolted enclosure crafted from galvanized or stainless steel to withstand harsh environments. Safety is prioritized through a standard dead-front design and GPO-3 barriers for maximum phase isolation, ensuring technician protection during critical operations. Customization to support utility-specific requirements is available on a standardized platform design.

Models:
10266 (35 kV, 200-600 Amphere, 3-phase)

Dimensions:
102”W x 66”D x 60”H

Contact Brooks for additional details.
